Overview

Product Overview

The Urban Plus Hinged door system features smooth flat panel profiles with an integrated bead to achieve a modern yet classic appearance. Capable of accommodating large high-performance double glazing to easily achieve enhanced thermal comfort and performance.

Offering a multitude of options, including open-in, open-out, single and double doors, the Urban Plus Hinged door also has the ability to be fully or partially glazed with glass or the aluminium panel system.

Single Glazed
Double Glazed
Wind and Water Rated
Acoustic Rated
WERS
Bushfire Rated
Flyscreen Option
Security Screen Option
Australian Standards
Declare Label Certified
Benefits
  • 36mm and 46mm panel thickness
  • Door panel also compatible with commercial framing
  • Premium quality 125mm architectural framing system
  • Exclusively designed components to improve the system’s performance and function
  • Single and double glazing options
  • Fully compatible with the Caprio and Caprice hardware range
  • Open-in and Open-out configurations available
  • Double rebated frame to seamlessly accommodate an Amplimesh security door or flyscreen door
  • Bushfire tested to BAL 40
BAL Rating
Low
12.5
19
29
40
Glazing
Single
Double
Triple
Cyclonic Region
C1
C2
C3
C4
N Rating
N1
N2
N3
N4
N5
N6
Acoustic RW Rating
22
27
32
37
42
47
53
View WERS ★ Rating

Details

Details

Product Specs
36mm Panel
Max. Recommended Panel Size
Height
2700
Width
1200
Dimensions
Frame Depth
125mm
Panel Thickness
36mm
Max. Product Performance
SLS (Pa)
4000
ULS (Pa)
9100
Water Open Out (Pa)
600
Water Open In (Pa)
300
Glazing Details
Single Glazed
4mm - 10mm
Double Glazed
16mm - 18mm
46mm Panel
Max. Recommended Panel Size
Height
3000mm
Width
1200mm
Max. Product Performance
SLS (Pa)
4500
ULS (Pa)
10000
Water Open Out (Pa)
600
Water Open In (Pa)
300
Glazing Details
Single Glazed
4mm - 12mm
Thick Glazed
14mm - 18mm
Double Glazed
19mm - 31mm
Max. Acoustic Rating
Rw (C;CTR)
33 (0;-1)
Bushfire tested to BAL40
Configurations
Arrangements

Specification Drawings

36mm Panel

397_JPEG_2105-01-36Panel

36mm Open Out Head & Sill

397_JPEG_2105-02-36OO-VER

36mm Open Out Jambs

397_JPEG_2105-03-36OO-HOR

36mm Open In Head & Sill

397_JPEG_2105-04-36OI-VER

36mm Open In Jambs

397_JPEG_2105-05-36OI-HOR

36mm Meeting Stiles

397_JPEG_2105-06-36MEETING

46mm Panel

397_JPEG_2105-07-46Panel

46mm Open Out Head & Sill

397_JPEG_2105-08-46OO-VER

46mm Alternative Open Out Sills

397_JPEG_2105-09-46AltSills

46mm Open Out Jambs

397_JPEG_2105-10-46OO-HOR

46mm Open In Head & Sill

397_JPEG_2105-11-46OI-VER

46mm Open In Jambs

397_JPEG_2105-12-46OI-HOR

46mm Meeting Stiles

397_JPEG_2105-13-46MEETING

46mm Cover Meeting Stiles

397_JPEG_2105-14-46COVERSTILES

Aluminium Panel Door

397_JPEG_2105-15-46SLAT PANEL

Screen Door Head & Sill

397_JPEG_2105-16-FLYSCREEN-VER

Screen Door Jambs & Meeting Stiles

397_JPEG_2105-17-FLYSCREEN-HOR
3D

3D Rendering

Downloads & Resources

Downloads

Brochures & Resources
Urban Plus Hinged Door Brochure
Download
Urban Plus Range Brochure
Download
Urban Plus Doors Extrusion Wall Chart
Download
Technical Information
UrbanPlus 397 Hinged Door Technical Manual
Urban Plus 397 Hinged Door Specification Document
Urban Plus Fixed Light Windows, Couplers & Adaptors Technical Manual
CAD Files
Urban Plus 397 Hinged Door CAD Files
Urban Plus Windows and Doors Wall Chart CAD Files
